10*60W Super Dotline LED waterproof lamp DL1060IP
Product application
Light Source
☀ Beam Section: 10x60W RGBW LED
☀ Strobe Section: 96 x 3W CW LED; 96 x 3W WW LED; 96 x 0.5W RGB LED
☀ 1Total Lumen Output of Fixture: 23,000 lumens
☀ Life Expectancy: 20,000 hours
☀ Strobe Section: 96 x 3W CW LED; 96 x 3W WW LED; 96 x 0.5W RGB LED
☀ 1Total Lumen Output of Fixture: 23,000 lumens
☀ Life Expectancy: 20,000 hours
Optical System
☀ Beam Angle:2.8°-31°(Beam section)
☀ Field Angle:5°-46°(Beam section)
☀ Motorized Zoom
☀ Field Angle:5°-46°(Beam section)
☀ Motorized Zoom
Pan &Tilt
☀ Tilt movement:200°(16bit)
☀ FAutomatic Tilt position correction.
☀ FAutomatic Tilt position correction.
Effects
☀ Pixel control of main LED
☀ The strip light have 12 individual section
☀ Strope:1-25Hzor random Beam, wash effects
☀ The strip light have 12 individual section
☀ Strope:1-25Hzor random Beam, wash effects
Software
☀ Multiple built-in programs
☀ Upgrade with DMX
☀ Channels:17/27/99/108/168CH
☀ Remote reset DMX address and fixture by DMX
☀ Upgrade with DMX
☀ Channels:17/27/99/108/168CH
☀ Remote reset DMX address and fixture by DMX
Display
☀ LCD display
☀ 4 buttons touch panel
☀ 4 buttons touch panel
Control
☀ DMX512 control
☀ Input signal isolation
☀ RDM protocol
☀ Input signal isolation
☀ RDM protocol
Electric Parameter
☀ AC180-240V 50/60HZ
☀ Power: 1160W
☀ Power: 1160W
Dimension & Weight
☀ Product size:1000x 290x120mm
☀ PNet weight: 23KG
☀ PNet weight: 23KG
Product feature
☀ Powerful Light Source & Pure Color：Equipped with professional light sources and expansive clear lenses, ensuring powerful light output with exceptional color purity and consistency.
☀ Silent & Efficient Motors：Tilt and zoom motors operate silently, rapidly, and with high precision, providing a smooth visual experience for your stage performances.
☀ Advanced Dimming System：Features an advanced linear dimming system that delivers a flawless dimming effect, outperforming comparable offerings.
☀ Multi-Function Control Modes：Supports DMX, RDM, Master/slave, Sound Active, and Auto modes, catering to diverse stage needs.
☀ Flexible Zoom & Color Mixing：Adjustable zoom angle and excellent color mixing effects allow you to create visual spectacles as you wish.
☀ High-Quality Durable Materials：Manufactured with high-quality materials, with an LED lifespan of up to 30,000 hours, ensuring long-term stable stage performance.
